Holybro Pixhawk Debug Adapter

$ 16.19

Holybro Pixhawk Debug Adapter Description: Holybro Pixhawk Debug Adapter provides a JTAG SWD and Serial interface to debug Pixhawk compatible hardware. Both the Target 6-pin (FMUV5) and Target 10-pin (FMUVxX) Pixhawk debug connector standards are supported. The built-in FTDI serial interface eliminates the need for a separate FTDI cable. The interface is specially designed to not backfeed the FMU, thus ensuring stable and reliable debugging regardless of power sequencing. Two Host JTAG interface standards are supported: The 10-pin ARM compatible with the Segger Jlink-mini and  20-pin compatible with the Segger Jlink or  STLink. The adapter also provides easily accessible ground points. When used with the 10-pin target cable it further supports two GPIO from the CPU that can be used to perform accurate signal timing. Target Reset via a push button, JTAG or optionly RTS from the serial interface is also supported over the 10-pin target interface. Follow us World Drone Market on YouTube to view more videos about the Holybro Product. Jumperable Options: JP1 – Normally Open. – Soldering this closed will bypass the RXD_DEBUG Back-feeding protection diode. This should not be needed unless the target already has the Back-feeding protection diode AND the target is not receiving data due to signaling levels. JP2 – Normally Open.  Soldering this closed will connect the RTS signal from the HOST to the CPU nRST line.  With this jumper soldered, the CPU nRST will be wired OR of the reset Button, the JTAG reset and the HOST RTS line. With it open the HOST RTS line is not connected. This could be used on automated test racks. Block Diagram
Send Inquiry
Categories: ,

Detail – 10 pack 16952 black on clear tape is compatible with Dymo letratag refills clear transparent plastic label refills. This thermal Non-laminated clear label maker tape 16952 measures 1/2 Inch W x 13ft L

Features – The replacement compatible for Dymo label maker refills clear 16952 has good adhesive and no sticky residue after removal. And this label maker refill clear 16952 is resistant to water, abrasion, temperature and will not smear or smudge

Machines – This clear tape is compatible with machines that use 12mm clear Letratag label refills. Such as LetraTag LT100H, LetraTag LT100H Plus, LetraTag LT100T, LetraTag LT110T, LetraTag QX 50, LetraTag 2000, LetraTag XR, LetraTag XM, LetraTag QR

Application – This letra tag refills clear label maker refill is self-adhesive. LT clear lable tape 12mm x 4m an economical choice for office, home, school and other indoor use. The back of the clear labels 16952 is split which makes it easy to peel and apply to common surfaces

Package – The replacement compatible for Dymo label maker refills clear have been tested multiple times. To ensure the condition of the product, please store unused clear label tape at normal room temperature and out of direct sunlight
